10~20KW All-in-one off-Gird Energy Storage System

SWP 's all-in-one battery system offers several advantages,such as Space Efficiency, Ease of Installation, Improved Efficiency, Enhanced Performance, Simplified Maintenance, Improved Safety.These advantages make them attractive options for various applications,such as residential, commercial, industrial, and portable power systems.

  • 5000W off-Grid batery system Efficiency ≥97% Stackable Battery Storage - Charging Temperature 0C-45C 120Kh/Module

    Product Description:

    SWP Stackable Battery Storage is an excellent choice for industrial and commercial battery storage systems as well as home energy storage. With a 5-year warranty, this battery storage system offers reliable and durable performance. It has an optimal charging temperature range of 0℃ to 45℃ and a wide discharging temperature range of -20℃ to 60℃. The system is equipped with built-in safety protections against DC reverse polarity, AC short circuit, leakage, and battery input reverse polarity. Weighing 120Kg per module, this battery storage system is ideal for large-scale energy storage in various settings, including homes, industrial facilities, and commercial environments.

    When it comes to battery storage systems, the Stackable Battery Storage is a compelling option to consider. It is designed to meet the energy storage needs of industrial, commercial, and residential applications, offering reliable and efficient performance.

    This battery storage system comes with a 5-year warranty, providing peace of mind and ensuring long-term reliability. It is built to withstand the demands of various environments and deliver consistent performance throughout its lifespan.

    With an optimal charging temperature range of 0℃ to 45℃, the Stackable Battery Storage ensures efficient and effective charging, maximizing the utilization of solar or grid power. The wide discharging temperature range of -20℃ to 60℃ allows for reliable power output even in extreme weather conditions.

    Safety is a top priority, and this battery storage system incorporates built-in protections against DC reverse polarity, AC short circuit, leakage, and battery input reverse polarity. These safety features help prevent accidents and ensure the system operates smoothly and securely.

    The Stackable Battery Storage is designed for scalability and flexibility, allowing for easy expansion of storage capacity as energy needs grow. Its modular design with a weight of 120Kg per module makes it suitable for large-scale energy storage installations in a variety of settings, including homes, industrial facilities, and commercial environments.

    Overall, the Stackable Battery Storage offers a reliable, durable, and efficient solution for energy storage, making it an excellent choice for those seeking to optimize their energy usage and reduce reliance on the grid.

    MODELTH-51200-SP
    Nominal Dc voltage51 .2V
    Battery capacity200Ah400Ah(200Ah*)
    Energy(kwh)10.24kwh20.48kwh
    Maximum Discharging current100A
    cycle Life6000cycles(80%DOD)
    certificationUN38.3,MSDS,CE-EMC,IEC62619,UL1973


    System GeneralData

    Temperature range-20~60℃
    Environmenthumidity0-95%
    Dimensions (H*w*D)mm1300*620*212mm1895*620*212mm
    Netweight (kg120KG220KG
    communicationmethodWIFl/4G
    Grid connection certificationCE-LVD;CE-EMC;EN50549;1/CEI-021;VDE4105/0124;G99;IEC61727/62116/61683;NA/EEA-NE7-CH2020


    Model                                                       SWP-3600ST          SWP-5000ST              SWP-6000ST

    PV input (DC)

    Recommend Max.PV input power8700Wp10000Wp11000Wp
    Max.PVVoltage600V
    Min.operation/start-up voltage40V / 50V
    Rated PV input voltage360V
    No.ofindependentMPPTinputs/strings2/1


    Efficiency

    Max.efficiency97.5%97.7%
    Eurpean efficiency97%97.3%


    Protection & Function

    ProtectionDC Revese Polarity /AC Short circuit /Leakage/battery input reverse polarity
    Surge ProtectionDC type Ⅱ/AC type Ⅱ
    DC swith (PV)/DC fuse(battery)Yes
    Battery input reverse polarity protectionYes


    General Data

    Dimensition(W*H*D)600*365*180mm
    Weight≤20Kg
    Degree Of ProtectionIP65
    Operating ambient emperature rang-25℃~60℃,0~100%
    Max.Operating Altitude4000m


    General Data

    Rated Output Power For Backup Load6000W


    Backup Data(Off-Grid Model)

    Rated Voltage220V/230V/240V(±2%)
    Frequency Range50HZ/60HZ(±0.5%)
    Rated out power3680W/3680VA5000W/5000VA5000W/6000VA
    Peak ourput power8400VA.10S

    Features:

    • Commercial Battery Storage System: Stackable Battery Storage

    • Operating Temperature: -20℃~60℃

    • Charging Temperature: 0℃~45℃

    • Weight: 120Kg/Module

    • Voltage: 40V~58.4V

    • Home Energy Battery Storage: Stackable Battery Storage

    • Operating Temperature: -20℃~60℃

    • Charging Temperature: 0℃~45℃

    • Weight: 120Kh/Module

    • Voltage: 40V~58.4V

    • High Voltage Battery Storage: Stackable Battery Storage

    • Operating Temperature: -20℃~60℃

    • Charging Temperature: 0℃~45℃

    • Weight: 120Kh/Module

    • Voltage: 40V~58.4V


    Technical Parameters:

    Product NameStackable Battery Storage
    Charge/Discharge Efficiency≥97%
    Charging Temperature0℃~45℃
    Voltage40V~58.4V
    Cycle Life≥6000
    Weight120Kh/Module
    Operating Temperature-20℃~60℃
    Warranty5 Years
    Discharging Temperature-20℃~60℃
    Safety ProtectionDC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity


    Applications:

    The stackable battery storage system is an energy storage batteries system that utilizes electric stacker batteries for efficient, safe, and reliable energy storage. This model, the SWP-48200ST, is manufactured in China and is certified with UL, MSDS, UN38.3, and CE. It has a minimum order quantity of 100 and a delivery time of 25 days. It is designed for use in a wide range of temperatures, from -20℃ to 60℃, and it has a weight of 120Kg/Module. This stackable battery storage system also has safety protection features, such as DC Revese Polarity, AC Short Circuit, Leakage, and Battery Input Reverse Polarity. It also has a very high charge/discharge efficiency of ≥97%, and it comes with a 5 year warranty. This stackable battery storage system is perfect for any application that requires reliable and efficient energy storage.

    Customization:

    Stackable Battery Storage

    • Brand Name: stackable battery system

    • Model Number: SWP-48200ST

    • Place of Origin: China

    • Certification: UL, MSDS, UN38.3, CE

    • Minimum Order Quantity: 100

    • Delivery Time: 25

    • Discharging Temperature: -20℃~60℃

    • Voltage: 40V~58.4V

    • Cycle Life: ≥6000

    • Warranty: 5 Years

    • Safety Protection: DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity

    Features:

    • Energy Storage Batteries

    • Home Storage Battery

    • Energy Storage Lithium Battery

    • Long Cycle Life Battery

    Packing and Shipping:

    Packaging and Shipping

    Stackable Battery Storage is packaged and shipped in boxes with the following dimensions: Length: 10.5 inches Width: 7.5 inches Height: 6 inches Weight: 2.5 pounds

    The product is securely packaged with foam padding to prevent any damage during shipping. It is shipped via FedEx, and the tracking number will be provided to the customer after the purchase has been made.

    FAQ:

    • Q: What is Stackable Battery Storage?

    • A: Stackable Battery Storage is a rechargeable battery storage product with brand name stackable battery system, model number SWP-48200ST, which is made in China and certified with UL, MSDS, UN38.3, CE.

    • Q: What is the minimum order quantity for Stackable Battery Storage?

    • A: The minimum order quantity for Stackable Battery Storage is 100.

    • Q: How long does it take for Stackable Battery Storage to be delivered?

    • A: It takes 25 days for Stackable Battery Storage to be delivered.

    • Q: Are there any safety certifications for Stackable Battery Storage?

    • A: Yes, Stackable Battery Storage is certified with UL, MSDS, UN38.3, CE.

    • Q: Where is Stackable Battery Storage made?

    • A: Stackable Battery Storage is made in China.
