ALL-IN-ONE battery system used in Electric Vehicle Charging Stations: All-in-one battery systems can be used in electric vehicle (EV) charging stations to store excess energy during low-demand periods and supply power during peak charging times. This helps balance the load on the electrical grid and optimizes the charging process.Emergency Power Backup: All-in-one battery systems are commonly employed as backup power sources in case of emergencies or power outages. They provide a reliable and immediate source of power for critical systems, such as emergency lighting, communication equipment, medical devices, and security systems.Renewable Energy Integration: All-in-one battery systems facilitate the integration of intermittent renewable energy sources, such as solar and wind, into the grid. They store excess energy generated during periods of high production and release it during times of low production, ensuring a smooth and consistent power supply.
5000W off-Grid batery system Efficiency ≥97% Stackable Battery Storage - Charging Temperature 0C-45C 120Kh/Module
SWP Stackable Battery Storage is an excellent choice for industrial and commercial battery storage systems as well as home energy storage. With a 5-year warranty, this battery storage system offers reliable and durable performance. It has an optimal charging temperature range of 0℃ to 45℃ and a wide discharging temperature range of -20℃ to 60℃. The system is equipped with built-in safety protections against DC reverse polarity, AC short circuit, leakage, and battery input reverse polarity. Weighing 120Kg per module, this battery storage system is ideal for large-scale energy storage in various settings, including homes, industrial facilities, and commercial environments.
When it comes to battery storage systems, the Stackable Battery Storage is a compelling option to consider. It is designed to meet the energy storage needs of industrial, commercial, and residential applications, offering reliable and efficient performance.
This battery storage system comes with a 5-year warranty, providing peace of mind and ensuring long-term reliability. It is built to withstand the demands of various environments and deliver consistent performance throughout its lifespan.
With an optimal charging temperature range of 0℃ to 45℃, the Stackable Battery Storage ensures efficient and effective charging, maximizing the utilization of solar or grid power. The wide discharging temperature range of -20℃ to 60℃ allows for reliable power output even in extreme weather conditions.
Safety is a top priority, and this battery storage system incorporates built-in protections against DC reverse polarity, AC short circuit, leakage, and battery input reverse polarity. These safety features help prevent accidents and ensure the system operates smoothly and securely.
The Stackable Battery Storage is designed for scalability and flexibility, allowing for easy expansion of storage capacity as energy needs grow. Its modular design with a weight of 120Kg per module makes it suitable for large-scale energy storage installations in a variety of settings, including homes, industrial facilities, and commercial environments.
Overall, the Stackable Battery Storage offers a reliable, durable, and efficient solution for energy storage, making it an excellent choice for those seeking to optimize their energy usage and reduce reliance on the grid.
| MODEL | TH-51200-SP | |
| Nominal Dc voltage | 51 .2V | |
| Battery capacity | 200Ah | 400Ah(200Ah*) |
| Energy(kwh) | 10.24kwh | 20.48kwh |
| Maximum Discharging current | 100A | |
| cycle Life | 6000cycles(80%DOD) | |
| certification | UN38.3,MSDS,CE-EMC,IEC62619,UL1973 | |
System GeneralData
| Temperature range | -20~60℃ | |
| Environmenthumidity | 0-95% | |
| Dimensions (H*w*D)mm | 1300*620*212mm | 1895*620*212mm |
| Netweight (kg | 120KG | 220KG |
| communicationmethod | WIFl/4G | |
| Grid connection certification | CE-LVD;CE-EMC;EN50549;1/CEI-021;VDE4105/0124;G99;IEC61727/62116/61683;NA/EEA-NE7-CH2020 | |
Model SWP-3600ST SWP-5000ST SWP-6000ST
PV input (DC)
| Recommend Max.PV input power | 8700Wp | 10000Wp | 11000Wp |
| Max.PVVoltage | 600V | ||
| Min.operation/start-up voltage | 40V / 50V | ||
| Rated PV input voltage | 360V | ||
| No.ofindependentMPPTinputs/strings | 2/1 | ||
Efficiency
| Max.efficiency | 97.5% | 97.7% |
| Eurpean efficiency | 97% | 97.3% |
Protection & Function
| Protection | DC Revese Polarity /AC Short circuit /Leakage/battery input reverse polarity |
| Surge Protection | DC type Ⅱ/AC type Ⅱ |
| DC swith (PV)/DC fuse(battery) | Yes |
| Battery input reverse polarity protection | Yes |
General Data
| Dimensition(W*H*D) | 600*365*180mm |
| Weight | ≤20Kg |
| Degree Of Protection | IP65 |
| Operating ambient emperature rang | -25℃~60℃,0~100% |
| Max.Operating Altitude | 4000m |
General Data
| Rated Output Power For Backup Load | 6000W |
Backup Data(Off-Grid Model)
| Rated Voltage | 220V/230V/240V(±2%) | ||
| Frequency Range | 50HZ/60HZ(±0.5%) | ||
| Rated out power | 3680W/3680VA | 5000W/5000VA | 5000W/6000VA |
| Peak ourput power | 8400VA.10S | ||
Commercial Battery Storage System: Stackable Battery Storage
Operating Temperature: -20℃~60℃
Charging Temperature: 0℃~45℃
Weight: 120Kg/Module
Voltage: 40V~58.4V
Home Energy Battery Storage: Stackable Battery Storage
Operating Temperature: -20℃~60℃
Charging Temperature: 0℃~45℃
Weight: 120Kh/Module
Voltage: 40V~58.4V
High Voltage Battery Storage: Stackable Battery Storage
Operating Temperature: -20℃~60℃
Charging Temperature: 0℃~45℃
Weight: 120Kh/Module
Voltage: 40V~58.4V
| Product Name | Stackable Battery Storage |
|---|---|
| Charge/Discharge Efficiency | ≥97% |
| Charging Temperature | 0℃~45℃ |
| Voltage | 40V~58.4V |
| Cycle Life | ≥6000 |
| Weight | 120Kh/Module |
| Operating Temperature | -20℃~60℃ |
| Warranty | 5 Years |
| Discharging Temperature | -20℃~60℃ |
| Safety Protection | DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity |
The stackable battery storage system is an energy storage batteries system that utilizes electric stacker batteries for efficient, safe, and reliable energy storage. This model, the SWP-48200ST, is manufactured in China and is certified with UL, MSDS, UN38.3, and CE. It has a minimum order quantity of 100 and a delivery time of 25 days. It is designed for use in a wide range of temperatures, from -20℃ to 60℃, and it has a weight of 120Kg/Module. This stackable battery storage system also has safety protection features, such as DC Revese Polarity, AC Short Circuit, Leakage, and Battery Input Reverse Polarity. It also has a very high charge/discharge efficiency of ≥97%, and it comes with a 5 year warranty. This stackable battery storage system is perfect for any application that requires reliable and efficient energy storage.
Stackable Battery Storage
Brand Name: stackable battery system
Model Number: SWP-48200ST
Place of Origin: China
Certification: UL, MSDS, UN38.3, CE
Minimum Order Quantity: 100
Delivery Time: 25
Discharging Temperature: -20℃~60℃
Voltage: 40V~58.4V
Cycle Life: ≥6000
Warranty: 5 Years
Safety Protection: DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity
Features:
Energy Storage Batteries
Home Storage Battery
Energy Storage Lithium Battery
Long Cycle Life Battery
Stackable Battery Storage is packaged and shipped in boxes with the following dimensions: Length: 10.5 inches Width: 7.5 inches Height: 6 inches Weight: 2.5 pounds
The product is securely packaged with foam padding to prevent any damage during shipping. It is shipped via FedEx, and the tracking number will be provided to the customer after the purchase has been made.
Q: What is Stackable Battery Storage?
A: Stackable Battery Storage is a rechargeable battery storage product with brand name stackable battery system, model number SWP-48200ST, which is made in China and certified with UL, MSDS, UN38.3, CE.
Q: What is the minimum order quantity for Stackable Battery Storage?
A: The minimum order quantity for Stackable Battery Storage is 100.
Q: How long does it take for Stackable Battery Storage to be delivered?
A: It takes 25 days for Stackable Battery Storage to be delivered.
Q: Are there any safety certifications for Stackable Battery Storage?
A: Yes, Stackable Battery Storage is certified with UL, MSDS, UN38.3, CE.
Q: Where is Stackable Battery Storage made?
A: Stackable Battery Storage is made in China.
