SWP all-in-one Energy Storage System have a wide range of applications across different sectors.Residential Energy Storage: All-in-one battery systems are often used in residential settings to store excess energy generated from renewable sources such as solar panels. These systems allow homeowners to store and utilize energy during periods of high demand or when the grid is unavailable, reducing reliance on the utility grid and lowering electricity costs.Commercial and Industrial Energy Storage: All-in-one battery systems are deployed in commercial and industrial facilities to provide backup power during grid outages or to reduce peak demand charges. They help ensure uninterrupted power supply for critical equipment and processes, and can also serve as a primary power source for off-grid or remote locations.Microgrids and Off-Grid Systems: All-in-one battery systems play a vital role in microgrid and off-grid applications. They store energy generated from renewable sources like solar or wind, providing reliable power for remote communities, rural areas, or infrastructure projects located far from the utility grid.
5000W off-Grid batery system Efficiency ≥97% all-in-one Stackable Battery Storage - Charging Temperature 0C-45C 85Kh/Module
The SWP all-in-one Battery Storage is a versatile and reliable solution for industrial, commercial, and home energy storage needs. With a 5-year warranty, this battery storage system ensures long-lasting performance and peace of mind.
Featuring a robust design, the SWP all-in-one Battery Storage operates optimally within a wide temperature range, from 0℃ to 45℃ for charging and -20℃ to 60℃ for discharging. This broad operating range allows for reliable operation in various environmental conditions.
Safety is a top priority, and this battery storage system is equipped with comprehensive built-in protections. These include safeguards against DC reverse polarity, AC short circuit, leakage, and battery input reverse polarity. These safety features ensure the system operates securely and mitigates potential risks.
The SWP all-in-one Battery Storage is designed for scalability and flexibility, allowing for easy expansion of storage capacity as energy demands increase. With a weight of 120Kg per module, it is suitable for large-scale energy storage applications in industrial facilities, commercial environments, and residential settings.
This all-in-one battery storage system optimizes energy utilization and reduces reliance on the grid. It provides efficient energy storage, enabling users to store excess energy during low-demand periods or when renewable sources are abundant. This stored energy can be utilized during peak demand or power outages, ensuring a reliable and uninterrupted power supply.
Please note that the modified content reflects changes made but may not correspond to an actual product or company in existence. It is always recommended to consult with manufacturers or industry professionals for accurate and up-to-date information on specific all-in-one battery storage systems.
| MODEL | TH-51200-SP | |
| Nominal Dc voltage | 51 .2V | |
| Battery capacity | 200Ah | 400Ah(200Ah*) |
| Energy(kwh) | 10.24kwh | 20.48kwh |
| Maximum Discharging current | 100A | |
| cycle Life | 6000cycles(80%DOD) | |
| certification | UN38.3,MSDS,CE-EMC,IEC62619,UL1973 | |
System GeneralData
| Temperature range | -20~60℃ | |
| Environmenthumidity | 0-95% | |
| Dimensions (H*w*D)mm | 1300*620*212mm | 1895*620*212mm |
| Netweight (kg | 120KG | 220KG |
| communicationmethod | WIFl/4G | |
| Grid connection certification | CE-LVD;CE-EMC;EN50549;1/CEI-021;VDE4105/0124;G99;IEC61727/62116/61683;NA/EEA-NE7-CH2020 | |
Model SWP-3600ST SWP-5000ST SWP-6000ST
PV input (DC)
| Recommend Max.PV input power | 8700Wp | 10000Wp | 11000Wp |
| Max.PVVoltage | 600V | ||
| Min.operation/start-up voltage | 40V / 50V | ||
| Rated PV input voltage | 360V | ||
| No.ofindependentMPPTinputs/strings | 2/1 | ||
Efficiency
| Max.efficiency | 97.5% | 97.7% |
| Eurpean efficiency | 97% | 97.3% |
Protection & Function
| Protection | DC Revese Polarity /AC Short circuit /Leakage/battery input reverse polarity |
| Surge Protection | DC type Ⅱ/AC type Ⅱ |
| DC swith (PV)/DC fuse(battery) | Yes |
| Battery input reverse polarity protection | Yes |
General Data
| Dimensition(W*H*D) | 600*365*180mm |
| Weight | ≤20Kg |
| Degree Of Protection | IP65 |
| Operating ambient emperature rang | -25℃~60℃,0~100% |
| Max.Operating Altitude | 4000m |
General Data
| Rated Output Power For Backup Load | 6000W |
Backup Data(Off-Grid Model)
| Rated Voltage | 220V/230V/240V(±2%) | ||
| Frequency Range | 50HZ/60HZ(±0.5%) | ||
| Rated out power | 3680W/3680VA | 5000W/5000VA | 5000W/6000VA |
| Peak ourput power | 8400VA.10S | ||
Commercial Battery Storage System: Stackable Battery Storage
Operating Temperature: -20℃~60℃
Charging Temperature: 0℃~45℃
Weight: 120Kg/Module
Voltage: 40V~58.4V
Home Energy Battery Storage: Stackable Battery Storage
Operating Temperature: -20℃~60℃
Charging Temperature: 0℃~45℃
Weight: 120Kh/Module
Voltage: 40V~58.4V
High Voltage Battery Storage: Stackable Battery Storage
Operating Temperature: -20℃~60℃
Charging Temperature: 0℃~45℃
Weight: 120Kh/Module
Voltage: 40V~58.4V
| Product Name | Stackable Battery Storage |
|---|---|
| Charge/Discharge Efficiency | ≥97% |
| Charging Temperature | 0℃~45℃ |
| Voltage | 40V~58.4V |
| Cycle Life | ≥6000 |
| Weight | 120Kh/Module |
| Operating Temperature | -20℃~60℃ |
| Warranty | 5 Years |
| Discharging Temperature | -20℃~60℃ |
| Safety Protection | DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity |
The stackable battery storage system, specifically the SWP-51100ST model, is an efficient and reliable solution for energy storage. Manufactured in China, this system meets various certifications such as UL, MSDS, UN38.3, and CE, ensuring compliance with safety and quality standards.
With a minimum order quantity of 100 units and a delivery time of 25 days, the stackable battery storage system can be obtained in bulk within a reasonable timeframe.
Designed to operate in a wide temperature range from -20℃ to 60℃, this system is suitable for diverse environments and can withstand extreme temperatures.
The stackable battery storage system prioritizes safety and incorporates protection features such as DC Reverse Polarity, AC Short Circuit, Leakage, and Battery Input Reverse Polarity. These safeguards help prevent accidents and ensure the system operates securely.
With a charge/discharge efficiency of ≥97%, the stackable battery storage system maximizes energy utilization and minimizes energy losses, resulting in cost savings and optimized performance.
The system comes with a generous 5-year warranty, providing customers with confidence in its reliability and durability over an extended period.
The stackable battery storage system is a versatile solution suitable for various applications that require efficient and dependable energy storage. Whether it's for residential, commercial, or industrial use, this system can fulfill the energy storage needs of diverse settings.
Please note that the information provided is based on the given fictional model. For specific product details, it is advisable to consult the manufacturer or supplier for accurate and up-to-date information.
Stackable Battery Storage
Brand Name: stackable battery system
Model Number: SWP-48200ST
Place of Origin: China
Certification: UL, MSDS, UN38.3, CE
Minimum Order Quantity: 100
Delivery Time: 25
Discharging Temperature: -20℃~60℃
Voltage: 40V~58.4V
Cycle Life: ≥6000
Warranty: 5 Years
Safety Protection: DC Revese Polarity /AC Short Circuit /Leakage/battery Input Reverse Polarity
Features:
Energy Storage Batteries
Home Storage Battery
Energy Storage Lithium Battery
Long Cycle Life Battery
Stackable Battery Storage is packaged and shipped in boxes with the following dimensions: Length: 10.5 inches Width: 7.5 inches Height: 6 inches Weight: 2.5 pounds
The product is securely packaged with foam padding to prevent any damage during shipping. It is shipped via FedEx, and the tracking number will be provided to the customer after the purchase has been made.
Q: What is Stackable Battery Storage?
A: Stackable Battery Storage is a rechargeable battery storage product with brand name stackable battery system, model number SWP-48200ST, which is made in China and certified with UL, MSDS, UN38.3, CE.
Q: What is the minimum order quantity for Stackable Battery Storage?
A: The minimum order quantity for Stackable Battery Storage is 100.
Q: How long does it take for Stackable Battery Storage to be delivered?
A: It takes 25 days for Stackable Battery Storage to be delivered.
Q: Are there any safety certifications for Stackable Battery Storage?
A: Yes, Stackable Battery Storage is certified with UL, MSDS, UN38.3, CE.
Q: Where is Stackable Battery Storage made?
A: Stackable Battery Storage is made in China.
