Equipped with a three-phase high-voltage inverter, the 25KWh high-voltage energy storage all-in-one is a safe, reliable andclean power supply system. The BYD batteries and the highly reliable BMS system ensure the safety of the system.The built-in high-precision meter and CT prevent back flow and provide load power monitoring, making the all-in-one more safe and reliable.The high-voltage energy storage all-in-one is IP65 rated and can be monitored wirelessly using Wi-Fi and GPRS. It also offers multiple operating modes to meet different user needs, supports seamless.
Equipped with a three-phase high-voltage inverter, the 25KWh high-voltage energy storage all-in-one is a safe, reliable andclean power supply system. The BYD batteries and the highly reliable BMS system ensure the safety of the system.
The built-in high-precision meter and CT prevent back flow and provide load power monitoring, making the all-in-one more safe and reliable.
The high-voltage energy storage all-in-one is IP65 rated and can be monitored wirelessly using Wi-Fi and GPRS. It also offers multiple operating modes to meet different user needs, supports seamless.
1. Product Description:
High Voltage Battery Storage
High Voltage Battery Storage is the perfect solution for home and industrial energy storage. It provides an efficient, reliable, and long-lasting battery storage system that can meet the needs of both residential and commercial customers. With a battery capacity of 50~100Ah and a charging time of 1~2 hours, this system is designed to provide energy storage solutions for a variety of applications. It is an environmentally friendly option with no environmental impact, and its high efficiency rate of 97% ensures that energy is stored and used efficiently. Moreover, its battery life exceeds 6000 cycles, providing reliable and continuous energy storage for the long term.
High Voltage Battery Storage is the ideal choice for those looking to invest in a home energy storage battery. Whether you need a reliable source of energy for your home or an industrial battery storage system, High Voltage Battery Storage is the perfect solution. It is a durable and cost-effective alternative for home energy storage batteries, providing homeowners with an efficient and long-lasting energy storage system.
| Model | A12-025KHAA | A12-025KHA1 | A12-025KHA2 |
| PV Input | |||
| Max Power (kW) | 12KW | 15KW | 18W |
| Max DC Voltage (V) | 1000V | ||
| MPPT Voltage (V) | 180V-850V | ||
| Single MPPT Max Input Current | 13A | ||
| MPPT | 2/1 | ||
| AC Output | |||
| Rated Output Power | 8KVA | 10KVA | 12KVA |
| Rated Output Discharge | 12.7A | 15.9A | 19.1A |
| Grid Voltage Range | 400V /360V~440V | ||
| Frequency | 50 /60Hz | ||
| PF | 1 | ||
| THDI | <3% | ||
| AC output | 3W+N+PE | ||
| EPS Output | |||
| Rated Power | 8.8KVA | 11KVA | 13.2KVA |
| Rated output Voltage | 400Vac | ||
| Rated current | 12.7A | 15.9A | 19.1A |
| Rated Frequency | 50Hz /60Hz | ||
| Automatic Switching Time | <20ms | ||
| THDU | <2% | ||
| Overload Capacity | 110%, 30S/120%, 10S/150%, 0.02S | ||
| Battery Data | |||
| Battery System | 512V ,50Ah | ||
| Battery Energy | 25kWh | ||
| Max quantities | 5 Set | ||
| Cycle Time | >10年(25℃/77F) | ||
| Rated Discharge/Charge Current | 40A | ||
| Communication Interface | CAN/RS485 | ||
| General Data | |||
| Europe Efficiency | 97.2% | 97.5% | 97.5% |
| MPPT Efficiency | 99.5% | 99.5% | 99.5% |
| Protect Degree | IP65 | ||
| Noise emissions | <60dB | ||
| Work Temperature | -10～+60℃ | ||
| Cooling Method | 风冷 | ||
| Relative humidity | 15%~85% | ||
| Altitude | 2000m(>2,000 | ||
| Size(mm) | 800*600*1833 | ||
| Weight (kg) | Customized | ||
| Self-Consumption | <3W | ||
| Monitor | LCD |
| Interface:RS485/Wifi/LAN/CAN | Yes |
| Safe Standard | IEC 62109-1&-2, IEC 62477, CE-EMC |
2. Features:
Product Name: High Voltage Battery Storage
Durability: High
Efficiency: 97%
Weight: Customized
Size: Customized
Reliability: High
Commercial Battery Storage Systems
Energy Storage System Battery
Energy Storage Lithium Battery
3. Technical Parameters:
| Parameter | Value |
|---|---|
| Efficiency | 97% |
| Voltage | 512V |
| Battery Life | ≥6000 |
| Maintenance | Low |
| Environmental Impact | No |
| Size | Customized |
| Cost | Low |
| Storage Capacity | 5Kw~15KW |
| Durability | High |
| Safety | High |
4. Applications:
The SWP-HV High Voltage lithium Battery Storage is a home energy storage battery for providing energy storage solutions. The product is designed for high-voltage energy storage, with a charging time of 1-2 hours, and a battery capacity of 50-100Ah. The battery is also lightweight and customizable, and requires low maintenance and offers high safety.
The SWP-HV is a perfect energy storage solution for homeowners who want to reduce their energy bills and take advantage of renewable energy sources. It can also be used in residential, commercial, and industrial applications, with the ability to store energy from solar panels, wind turbines, and other sources for later use.
The SWP-HV High Voltage lithium Battery Storage is the ideal choice for those looking for a reliable, energy-efficient home energy storage solution. With its low maintenance and high safety, the SWP-HV is the perfect solution for residential and commercial energy storage.
5. Customization:
SWP High Voltage Battery Storage
The SWP High Voltage Battery Storage System is a commercial and household energy storage battery that provides superior energy storage capacity and safety. It is the perfect solution for those who require a reliable and durable energy storage solution. The SWP-HV model is made in China and features a storage capacity ranging from 5Kw to 15Kw. The battery is designed with high durability, low cost, and high safety standards. It is the perfect choice for those who need a reliable energy storage battery for their home or business.
The SWP High Voltage Battery Storage System provides a powerful and reliable energy storage solution for households and businesses. It is a safe and efficient energy storage solution that is designed to provide cost-effective and reliable energy storage. The battery is designed to be durable and safe, and it offers a low cost alternative to traditional energy storage solutions. The battery is also designed to be lightweight and easy to install. With its high safety standards, it is the perfect choice for those looking for a reliable energy storage solution.
The SWP High Voltage Battery Storage System is the perfect choice for those looking for an energy storage solution that is reliable, durable, and cost-effective. It offers high safety standards, low cost, and high durability. It is the perfect choice for homeowners and businesses who need an efficient and reliable energy storage battery. This energy storage lithium battery is the perfect solution for those looking for a dependable and reliable energy storage solution.
6. Support and Services:
High Voltage Battery Storage Technical Support and Service
We provide comprehensive technical support and services to ensure the successful installation and operation of High Voltage Battery Storage systems. Our team of experienced technicians are available to provide on-site and off-site support as well as remote troubleshooting. Our team is highly qualified and certified to handle any and all support and service needs that you may have.
We provide the following services for High Voltage Battery Storage systems:
Installation and commissioning assistance
Preventative maintenance and repair services
Software upgrades and troubleshooting
System optimization and diagnostics
Technical training and education
We are committed to providing quality technical support and services for all of our customers. If you have any questions or concerns, please do not hesitate to contact us.
7. Packing and Shipping:
Packaging and Shipping
High Voltage Battery Storage products must be packaged and shipped in accordance with the following guidelines:
Packaging must include cushioning materials to prevent any shifting of the product during transit.
Packaging must be strong enough to protect the product from any external damage.
Products must be shipped in a manner that prevents any moisture build-up.
Products must be shipped with adequate documentation, including a tracking number.
8. FAQ:
Q: What is the Brand Name and Model Number of this product?
A: The Brand Name is SWP and the Model Number is SWP-HV.
Q: Where is this product made?
A: This product is made in China.
Q: What is a High Voltage Battery Storage?
A: High Voltage Battery Storage is a battery storage system designed to provide high voltage energy to a variety of applications.
Q: What are the benefits of using a High Voltage Battery Storage system?
A: High Voltage Battery Storage systems provide efficient energy storage and are capable of storing large amounts of energy for long periods of time. They are also more reliable and durable than other types of energy storage systems.
Q: What type of applications can a High Voltage Battery Storage system be used for?
A: High Voltage Battery Storage systems can be used for a variety of applications, including renewable energy storage, electric vehicle charging, and backup power supply.
